Darshan Safety Zone is a leading manufacturer and supplier of Ceramic Fiber Fabric in West Bengal, offering high-performance thermal insulation solutions
for extreme temperature applications.
Our manufacturing unit is based in Ahmedabad, Gujarat, India.
🧵 Product Overview
DSZCF3.0 Ceramic Fiber Fabric
Ceramic Fiber Fabric (DSZCF3.0) is a high-performance woven textile made from premium alumina-silica fibers and reinforced with stainless steel (SS) wire
for enhanced strength and durability.
Engineered for extreme heat environments, it provides excellent thermal insulation, flexibility, and resistance to chemical and mechanical stress.
- Manufactured using high-quality ceramic fiber yarn
- Reinforced with SS metallic wire for higher tensile strength
- Lightweight, flexible, and easy to install
- Suitable for high-temperature industrial applications
⚙️ Technical Specifications
- Model: DSZCF3.0
- Continuous Temperature: Up to 1260°C
- Short-Term / Peak Temperature: Up to 1400°C – 1760°C
- Melting Point: Approx. 1760°C
- Thickness Available: 2.0 mm / 3.0 mm / 4.0 mm
- Weight: 1000 GSM / 1500 GSM
- Standard Width: 610 mm / 1000 mm / 1200 mm
- Roll Size: 1 meter x 30 meters
- Color: White
- Weave Type: Plain
- Reinforcement: Stainless Steel (SS) Metallic Wire
- Conductivity: Electrically non-conductive (typical application-based)
- Standards: ASTM C1185, ISO 14001
🚀 Features
- Excellent thermal insulation and fire resistance
- High tensile strength due to SS wire reinforcement
- Resistant to thermal shock, chemicals, and abrasion
- Low thermal conductivity for energy efficiency
- Non-combustible and safe for high-temperature environments
- Moisture-resistant with low water absorption
- Long service life under extreme conditions
🏭 Applications
- Heat shields for aerospace and defense
- Welding blankets and fire curtains
- Furnace insulation and thermal barriers
- Expansion joints and industrial seals
- Insulation for pipes, ducts, and reactors
- Protective clothing components
- Acoustic and sound insulation systems
- Petrochemical, power generation, and metallurgy industries
- Energy storage systems (battery & fuel cell protection)
💡 Benefits
- Reduces heat loss and improves energy efficiency
- Protects equipment and personnel from heat exposure
- Performs reliably in harsh industrial environments
- Durable and cost-effective insulation solution
- Suitable for continuous and high-peak temperature applications
⭐ Why Choose Darshan Safety Zone
- Expertise in high-temperature insulation materials
- Premium-quality ceramic fiber manufacturing
- Trusted across aerospace, power, and industrial sectors
- Customization available as per industrial requirements
❓ Frequently Asked Questions (FAQs)
1. What temperature can Ceramic Fiber Fabric withstand?
It can handle continuous temperatures up to 1260°C and peak exposure up to 1400°C – 1760°C.
2. Is the fabric flexible and easy to install?
Yes, it is lightweight and flexible, making it easy to install in complex setups.
3. What reinforcement is used in the fabric?
It is reinforced with stainless steel (SS) metallic wire for added strength.
4. Can it be used for fire protection applications?
Yes, it is non-combustible and ideal for welding blankets, fire curtains, and heat shields.
5. Is it resistant to chemicals and moisture?
Yes, it offers excellent resistance to chemicals, abrasion, and moisture.
